VMR-FR3300L
300kg Rated Loaded
.png)
VB1
Humanoid Robot Versabot for handling
Suitable for industries such as automotive, construction machinery, home appliances, electrical & electronics, etc.
FEATURES
Precise Positioning
Utilizes vision-based SLAM for autonomous navigation combined with 2D code markers to achieve accurate placement.
Stable Docking
Employs self-developed industrial cameras to accurately guide the robot to assembly positions.
Self-developed Core
Employs independently developed main control and business modules, offering high integration, stability, and reliability.
Efficiency and Productivity
Supports multiple autonomous charging methods such as scheduled, fixed-point, and low-power return-to-home.
Safety Protection
Implements 3D vision obstacle avoidance and intelligently detects low and overhead obstacles, ensuring safer operation.
TECH SPECS
1100
Rotation Diameter(mm)
2
Speed(m/s)
1200
Lifting Height(mm)
2
Load Capacity(kg/per arm)
Basics
Dimensions(L*W*H)
700L*606W*1585 mm
Net Weight
≤150kg
Rotation Diameter
Φ1100mm
Capacities
Lifting Height
720-1200mm
Gripping Load
2kg*2
Docking Method
Face-to-face docking
Safety
Protective Range
360° Vision Obstacle Avoidance
Protective Measures
Three-level protection: deceleration, gradual stop, emergency stop
Laser Obstacle Avoidance
360° coverage by front & rear laser
E-stop Button
The reachable range of a single hand around the robot
Audio-Visual Alarm
Light indication+ Audio prompt
Motion
Drive Mode
Four hub motors
Navigation Mode
Vision SLAM
Driving Direction
Forward, backward, rotate, Lateral movement
Speed
2m/s
Navigation Accuracy
±10mm
Docking Accuracy
±10mm
Battery
Battery Type
LFP
Battery Capacity
48V 50Ah
Battery Life
≥8h
Charging Method
Automatic / Manual charging
Charging Time
2h
Life Cycle
1500 cycles
HMI
LCD Panel
Standard
Light Indication
Robot status, fault alarm, battery power, etc.
Sound Prompt
Turning, warning, music playback, etc.
Button Operation
E-stop, power switch, operation controls
