Dimensions(L*W*H)

1334 mm * 934 mm * 778 mm

Net Weight

600 kg

Rotation Diameter

φ1600 mm

Lifting Height

350 mm

Rated Load

1200 kg

Docking Height

1200 mm(Depends on roll diameter)

Lifting Method

Lifting roll

Material Weighing

Optional

Protective Range

Including the body and the load-carrying rack

Protective Measures

Three-level protection: deceleration, gradual stop, emergency stop

Laser Obstacle Avoidance

360° coverage by front & rear laser

Safety Edge

All-round protection

E-stop Button

The reachable range of a single hand around the robot

Audio-Visual Alarm

Light indication+ Audio prompt

3D Vision Obstacle Avoidance

Optional

Drive Mode

2 steering wheel drive

Navigation Mode

Natural navigation

Driving Direction

Omnidirectional, rotation

Speed

0~1.0 m/s

Navigation Accuracy

±20 mm

Docking Accuracy

±10 mm (laser docking), ±5 mm (QR code visual docking)

Loading Docking Accuracy

≤ ±5 mm

Battery Type

LFP

Battery Capacity

48V 100AH

Battery Life

≥8h

Charging Method

Automatic / Manual charging

Charging Time

2.5 h

Life Cycle

1500 cycles

LCD Panel

Optional

Light Indication

Robot status, fault alarm, battery power, etc.

Sound Prompt

Turning, warning, music playback, etc.

Manual Remote Controller

Support

Expansion Interface

RJ45(100MB)

Application Scenarios

Indoor

Operating Temperature

0~40℃

Humidity

10~90%RH, no condensation

Ground Slope

≤ 5% / 3°

Obstacle Crossing Height

≤ 5 mm
