Dimensions (L*W*H)

2910 mm * 980 mm * 2210 mm

Net Weight

700 kg

Rotation Diameter

φ4300 mm

Rated Load

3000 kg

Lifting Height

135 mm

Load Center

1200 mm

Fork Size (L*W*H)

2400 mm * 195 mm * 55 mm (x2)

Fork Outer Width

680 mm(Standard)

Protective Range

360° coverage

Protective Measures

Three-level protection: deceleration, gradual stop, emergency stop

Laser Obstacle Avoidance

360° coverage by 3 front & rear laser sensors

Safety Edge

Front half-pack protection

E-stop Button

The reachable range of a single hand around the robot

Audio-Visual Alarm

Light indication+ Audio prompt

Vision Obstacle Avoidance

Optional

Drive Mode

Single steering wheel

Navigation Mode

Natural navigation, vision / laser SLAM

Driving Direction

Forward, backward, rotate, left / right turn

Speed

0~1.5 m/s

Stop Position Accuracy

±10 mm

Stop Angle Accuracy

±1°

Battery Type

LFP

Battery Capacity

24V 200AH

Battery Life

6-8h

Charging Method

Automatic / Manual charging

Charging Time

≤3h

Life Cycle

2000 cycles

LCD Panel

Support

Light Indication

Robot status, fault alarm, battery power, etc.

Sound Prompt

Turing, warning, music playback, etc.

Button Operation

Emergency stop button, power switch button, operation button

Manual Remote Controller

Support

Expansion Interface

RJ45(100MB)

Application Scenarios

Indoor

Operating Temperature

0~40℃

Humidity

10~90%RH, no condensation

Ground Slope

≤ 5%(no-load) / 3%(full-load)

Network Communication

WiFi IEEE802.11 a/b/g/n/ac/ax, 5G(optional)

Aisle Width for 90° Pallet Pickup

4500 mm (pallet: 1200*1200 mm)
